LRF20M3PS is a cost-effective solution we specially provide for distance measurement. This specification is easy to operate, flexible to install, and easy to expand. The measurement range can reach 20 meters, and also suitable for measuring static targets. It is widely used in security, industry, detection, automation and other applicable fields.



  Features :

  • Compact and lightweight design
  • Phase-shift measurement
  • Low power consumption
  • Single & Continuous measurement
  • Record maximum and minimum distance
  • Custom made service available

Technical Information :

  Model Name LRF20M3PS
  Measurement Range
0.045m ~ 20m
  Measurement Frequency 1~3Hz
  Measurement Accuracy ±3.0mm @ 25°C
  Wavelength 650 nm
  Laser Safety <0.95W (Class 2)
  Measurement Method
Phase-shift
  Anti-ambient light
30K LUX
  Communication Interface 3.3V TTL (UART)
  Interface Connector 8 pin 0.5 mm FFC & FPC
  Input Voltage 3.3~3.6V DC
  Dimensions 21 x 11 x 26mm
  Weight ~60g
  Operating Temperature 0°C~40°C


Demo Tool Download :

 LRF Test Tool.exe

Note:

Should you need any further support, please feel free to contact us.

20m Economical Laser Distance Sensor Module - LRF20M3PS

Key Properties

- Measurement Range: 0.045m ~ 20m
- Frequency: 1~3Hz
- Accuracy: ±3mm @ 25°C
- Wavelength: 650 nm
- Laser Safety: <0.95mW (Class 2)
- Communication Interface: TTL (UART)

Datasheet
